Bernardo | SKU: 06-1621XL

HPS 45 Hydraulic Steel Profile Shear

Name: HPS 45 Hydraulic Steel Profile Shear
Brand: Bernardo
SKU: 06-1621XL
Price: 8332.60 EUR
Availability: InStock

€8.332,60

Tax included Shipping calculated at checkout.

Contattaci

disponibile entro 2/3 mesi

Pre-order now to make sure you don't miss out! We'll ship it to you as soon as it's available.

Let me know if you want a more formal or more playful version!

Subscribe to our newsletter

Get the latest updates on all our new collections, sales, offers and product arrival dates.

Technical Specifications	Value
punching
Room Strength	45 Tons
Max. Storage Capacity	12 mm
Diameter x Thickness	22 mm
Stroke Length	60 mm
Stroke Frequency (20 mm)	8 cpm (strokes per minute)
Extension Length	200 mm
Max. Hole Size (Standard)	22 mm
Max. Hole Size (Optional)	Φ 40 mm
Working Height	955 mm
Flat steel station
Max. Thickness of Flat Sheet Metal	12 mm
Max. Width of Flat Sheet Metal	330 mm
Blade Length	318 mm
Profile Angle	7th
Working Height	940 mm
Structural steel station
90°	100 x 100 x 10 mm
45°	70 x 70 x 6 mm
Working Height	1090 mm
U-profile/ I-profile (Optional)	80 x 45 x 5 / 80 x 45 x 5 mm
T-profile (Optional)	100 x 100 x 10mm, 40 x 40 x 5mm
steel bar shears
Round Profile	30 mm
Square Profile	30 x 30 mm
Working Height	1150 mm
Engine Power	3 kW
Machine Dimensions (L x W x H)	1200 x 520 x 1500 mm
Approximate Weight	1000 kg
Optional

⚙️ Qual è la forza di punzonatura della HPS 45?

🛡️ Che materiali può lavorare la HPS 45?

📐 Qual è il diametro massimo dei fori realizzabili?

🔧 Quali profili può tagliare la cesoia?

🚚 Quanto pesa la macchina e come viene consegnata?

📊 Quali settori utilizzano la HPS 45?

Customer Reviews
