Description
Titan 660 x 1500 production lathe with 3-axis digital readout
The Titan 660 x 1500 parallel lathe is a robust, modern, and high-performance machine, ideal for intensive machining in the mechanical engineering, plant construction, and custom production sectors. Equipped with a wide range of feeds, quick tool change, mechanical clutch, and a 3-axis digital readout, it offers a perfect combination of power, precision, and operating comfort.
Main features
• Ideal for mechanical, industrial construction, production and single-piece work
• Practical central control for feeds and threads with guide shaft and feed shaft
• Prismenbett (prismatic bench) made of grey cast iron, induction hardened and precision ground
• Large 105mm spindle bore for large diameter workpieces
• Smooth start via mechanical disc clutch
• Stiffened structure with internal ribs to reduce vibrations during machining
• Planar machining with excellent chip removal performance
• Precision angular roller bearings on the main shaft
• Hardened and ground gears and shafts also in the feed change
• Longitudinal and transverse rapid feed as standard to reduce downtime
• Electromechanical foot brake and motor with magnetic brake for safety and speed
• ES-12 V 3-axis digital display with LCD screen
Technical table
| Characteristic | Value |
|---|---|
| Distance between tips | 1500 mm |
| Tip height | 330 mm |
| Maximum turning diameter on the bench | 660 mm |
| Turning diameter on recess | 900 mm |
| Turning diameter on cross slide | 460 mm |
| Bench width | 400 mm |
| Spindle hole | 105 mm |
| Spindle attachment | DIN 55029, D1-8 |
| Spindle speed range | (16) 25 – 1600 rpm |
| Longitudinal advances | (25) 0.044 – 1.48 mm/rev |
| Transversal advances | (25) 0.022 – 0.740 mm/rev |
| Metric threads | (54) 0.45 – 120 mm |
| Inch threads | (54) 7/16 – 80 TPI |
| Tailstock quill diameter | 90 mm |
| Tailstock quill stroke | 235 mm |
| Tailstock quill attachment | MK 5 |
| Engine power | 7.5 kW (10.0 HP) |
| Machine dimensions (L x W x H) | 3130 x 1200 x 1520 mm |
| Weight | approx. 2700 kg |
Package Contents
• ES-12 V 3-axis digital display with LCD display
• Rutschkupplung (safety coupling)
• Rapid longitudinal and transverse advances
• LED lighting
• PS3 3-jaw self-centering chuck – 315 mm / D8
• 450 mm drive plate
• Fixed bezel (Ø max. 180 mm)
• Movable bezel (Ø max. 120 mm)
• 2 counterpoints
• Motor with CE compliant magnetic brake
• Pedal with integrated brake compliant with CE standards
• Initial fill with Shell Tellus 46
• Cooling system
• Quick-change tool holder with 4 inserts
• Tool holder protection
• Replacement gear set
• Reducing compass
• Rear protective bulkhead
• Cable duct with cable chain
• Service keys and manuals
